Adding engine and protocol support

This guide separates two ideas that are easy to conflate:

Concept	Meaning	Example
Backend engine	A cluster type QueryFlux routes queries to. It has an adapter that talks to the real database (HTTP, MySQL wire, embedded library, AWS SDK, …).	Trino, DuckDB, StarRocks, Athena
Frontend protocol	How clients connect to QueryFlux (ingress). SQL enters with a FrontendProtocol and a default source dialect for translation.	Trino HTTP, PostgreSQL wire, MySQL wire, Flight SQL

Adding PostgreSQL wire as a client entrypoint is not the same as adding “PostgreSQL” as a backend: today, PostgresWire is already a frontend in queryflux-frontend; traffic still lands on the shared dispatch path and is sent to whatever backend adapter routing chose (often Trino).

Use the sections below depending on whether you are extending Studio, a backend adapter, or a frontend listener.

---

Part A — Backend engine (Rust)

Goal: a new engine value in cluster config, a live adapter, validation, translation target dialect, and wiring in the binary.

Registration overview

Backends are not loaded dynamically. Each engine is compiled in and registered explicitly. Data flow:

1. Postgres / YAML → engine_key column + config JSONB → ClusterConfigRecord::to_core() uses parse_engine_key and JSON helpers → typed ClusterConfig.
2. Binary → registered_engines::build_adapter(...) matches EngineConfig and calls the adapter’s try_from_cluster_config (see crates/queryflux/src/registered_engines.rs).
3. Adapter → reads only the ClusterConfig fields it needs (endpoint, auth, region, …) and constructs itself; startup and hot reload both use the same factory.

JSONB stores per-cluster, per-engine payload without schema migrations; ClusterConfig in core is the typed view after to_core(). Engine-specific wiring belongs in try_from_cluster_config, not in main.rs.

1. Core model (queryflux-core)

• EngineConfig — Add a variant in crates/queryflux-core/src/config.rs (serde camelCase in JSON/YAML, e.g. myEngine).
• EngineType — Add a variant in crates/queryflux-core/src/query.rs if the backend is distinct for metrics, translation, or dispatch.
• engine_registry (crates/queryflux-core/src/engine_registry.rs) — Keep these in sync when you add a variant:
  • engine_key(&EngineConfig) — EngineConfig → stable string key (must match the adapter descriptor and Studio).
  • parse_engine_key(&str) — inverse mapping for the engine_key column in Postgres / API.
  • impl From<&EngineConfig> for EngineType — single place for config → runtime EngineType (cluster manager and main.rs use this instead of ad-hoc matches).
• EngineType::dialect() — Return the SqlDialect used as the translation target (and extend SqlDialect / is_compatible_with in translation if needed). See query-translation.md.
• ClusterConfig fields — Add any new top-level fields (region, paths, engine-specific blobs). Prefer keeping engine-specific secrets and options in config JSON for Postgres-backed clusters; extend the typed struct when YAML and validation need them everywhere.

2. Adapter crate (queryflux-engine-adapters)

• Add a module (e.g. src/myengine/mod.rs) implementing EngineAdapterTrait (submit_query, poll_query, cancel_query, health_check, engine_type, supports_async, and optionally fetch_running_query_count, base_url, Arrow/catalog hooks as needed).
• Implement descriptor() -> EngineDescriptor with:
  • engine_key, display_name, description, hex
  • connection_type (Http, MySqlWire, Embedded, ManagedApi)
  • supported_auth and config_fields (these drive /admin/engine-registry and should stay aligned with Studio)
  • implemented: true when the adapter is actually wired in main
• Export the module from crates/queryflux-engine-adapters/src/lib.rs and add the crate dependency if you introduce new third-party crates.

Factory — try_from_cluster_config

Implement on your adapter struct so all field extraction and validation for that engine live next to the adapter (not in registered_engines.rs):

• Sync (most engines):

  fn try_from_cluster_config(
      cluster_name: ClusterName,
      group_name: ClusterGroupName,
      cfg: &ClusterConfig,
      cluster_name_str: &str,
  ) -> queryflux_core::error::Result<Self>

• Async (e.g. Athena — AWS client setup): same parameters, async fn, returns Result<Self>.

Use QueryFluxError::Engine(format!(…)) for failures; include cluster_name_str in messages so startup and reload logs identify the cluster. Reference implementations: TrinoAdapter and StarRocksAdapter (trino/mod.rs, starrocks/mod.rs), DuckDbAdapter / DuckDbHttpAdapter (duckdb/mod.rs, duckdb/http.rs), AthenaAdapter (athena/mod.rs).

Keep pub fn new(...) (or async fn new) as the low-level constructor if you want tests to build adapters without a full ClusterConfig; try_from_cluster_config can delegate to new after parsing cfg.

3. Binary wiring (crates/queryflux)

Registration is centralized in crates/queryflux/src/registered_engines.rs:

• all_descriptors() — Append MyEngineAdapter::descriptor() to the returned vec!. main.rs builds EngineRegistry::new(registered_engines::all_descriptors()) for validation and GET /admin/engine-registry.
• build_adapter(cluster_name, placeholder_group, cluster_cfg, cluster_name_str).await — Returns anyhow::Result<Arc<dyn EngineAdapterTrait>>. Add a match arm on EngineConfig::MyEngine that calls MyEngineAdapter::try_from_cluster_config(...), maps QueryFluxError to anyhow::Error (same helper as other arms), and wraps Arc::new(...). Startup uses .context(...)? on the result; hot reload in build_live_config logs a warning and continue on error — behavior stays in main.rs, not in the factory.

Do not add a second adapter-construction match in main.rs.

Not implemented yet: e.g. EngineConfig::ClickHouse is handled inside build_adapter with anyhow::bail! until a ClickHouseAdapter and try_from_cluster_config exist.

• EngineType for cluster state — In main.rs and anywhere else (e.g. group member ClusterState), use EngineType::from(engine_config) from engine_registry.rs. queryflux-cluster-manager engine affinity uses the same From impl (see strategy.rs).

• Special rules — Search for engine-specific checks (e.g. queryAuth / impersonation) and extend validation if your engine has constraints.

4. Dispatch and frontends (queryflux-frontend)

• Shared query execution goes through dispatch_query / execute_to_sink. Usually no change if the new engine only differs in the adapter; if you need a special execution path (like Trino raw HTTP), follow the existing engine-specific branches.
• Per-protocol handlers (Trino HTTP, Postgres wire, …) should keep using the shared dispatch layer unless the protocol requires a dedicated contract.

5. Persistence (queryflux-persistence) — why touch it if config is JSON?

The table stores engine_key as its own column plus a config JSONB blob. The DB does not load straight into the proxy as opaque JSON: code paths call ClusterConfigRecord::to_core(), which must produce a typed ClusterConfig (including EngineConfig).

So persistence changes are not “because Postgres needs a JSON schema.” They are because of this explicit conversion layer:

1. ClusterConfigRecord::to_core — Calls parse_engine_key from queryflux-core (next to engine_key). Extend parse_engine_key when you add an engine; you do not maintain a second duplicate string match in persistence.
2. UpsertClusterConfig::from_core — Uses engine_key(&EngineConfig) from core to set the engine_key column when seeding from YAML.

Extra JSON keys that only live inside config and are already read in to_core (e.g. endpoint, region, authType, …) usually need no persistence change beyond the engine-key match. You only extend the s("…") / b("…") helpers in to_core (and the matching from_core inserts) if you add new top-level persisted fields on ClusterConfig that should round-trip through that JSON.

Hot reload often uses list_cluster_configs → records → to_core() → build_live_config; the same conversion applies.

6. Optional: routing config

• If operators choose the new group via router JSON (RouterConfig variants), no change unless you add a new router type.
• Protocol-based routing maps frontend labels to group names; it does not list backend engines.

7. Tests and docs

• Add or extend e2e tests under crates/queryflux-e2e-tests if you have a dockerized target.
• Update system-map.md component status if you document supported engines there.

8. Suggested order of work (backend only)

1. EngineConfig / EngineType + engine_key / parse_engine_key / From<&EngineConfig> for EngineType + dialect() if needed.
2. ClusterConfig fields if the engine needs new top-level keys (and persistence to_core JSON extraction if those keys live in JSONB).
3. Adapter module: EngineAdapterTrait, descriptor(), try_from_cluster_config.
4. registered_engines.rs: descriptor in all_descriptors(), arm in build_adapter.
5. Run cargo build -p queryflux; exercise YAML and Postgres load + admin upsert if applicable.

---

Part B — QueryFlux Studio (UI, TypeScript / React)

Studio is the Next.js app under ui/queryflux-studio/. It does not run wire protocols; it calls the Admin API (ADMIN_API_URL, default http://localhost:9000) for clusters, groups, routing, and scripts.

Backend engines are registered in Studio through StudioEngineModule objects: one file per engine under lib/studio-engines/engines/, aggregated in lib/studio-engines/manifest.ts. That manifest drives ENGINE_REGISTRY, catalog slots for implemented backends, optional flat-form validation, engine-affinity dropdown entries, and extra findEngineByType aliases.

The proxy still exposes descriptors at GET /admin/engine-registry. Studio does not load that at runtime yet, so Rust descriptor() and each studio module’s descriptor field must stay aligned by hand (same engineKey, configFields keys, auth shapes, etc.). Shared TypeScript types live in lib/engine-registry-types.ts; lib/engine-registry.ts only re-exports helpers and builds ENGINE_REGISTRY from the manifest.

Where users see engines

User action	UI entrypoint	What must know your engine
Create cluster	Clusters → Add cluster (components/add-cluster-dialog.tsx)	Expanded ENGINE_CATALOG (includes studio slots) + findEngineDescriptor + validateClusterConfig / validateEngineSpecific + toUpsertBody
Edit cluster	Clusters grid → cluster card → Edit (app/clusters/clusters-grid.tsx)	Same + mergeClusterConfigFromFlat / buildClusterUpsertFromForm + EngineClusterConfig
View config	Cluster detail / engine config view in clusters-grid.tsx	findEngineDescriptor for labels; unknown key shows “add to engine registry” warning
Group strategy engine affinity	Engines → group dialog → strategy (components/group-form-dialog.tsx)	ENGINE_AFFINITY_OPTIONS is built by buildEngineAffinityOptionsFromManifest() from each module’s engineAffinity field (omit label override, or set engineAffinity: false to exclude, e.g. Athena).
Live utilization cards	Engines (Groups) page (app/engines/page.tsx)	findEngineByType; studio modules contribute aliases via extraTypeAliases (merged with static dialect aliases in components/engine-catalog.ts)

1. Studio engine module (primary registration)

Types: ui/queryflux-studio/lib/studio-engines/types.ts — StudioEngineModule.

Per engine: ui/queryflux-studio/lib/studio-engines/engines/<engine>.ts

Export a constant (e.g. trinoStudioEngine) with:

• descriptor — Full EngineDescriptor (must match Rust: engineKey, connectionType, supportedAuth, configFields, implemented, branding hex, etc.). Extend ConnectionType / AuthType in lib/engine-registry-types.ts if Rust added a variant.
• catalog — category, simpleIconSlug, catalogDescription for the engines grid / picker (display name and supported come from the descriptor when the catalog is expanded).
• validateFlat (optional) — Cross-field checks before save (e.g. Trino basic vs bearer). Dispatched by validateEngineSpecific in lib/studio-engines/validate-flat.ts (re-exported from lib/cluster-persist-form.ts).
• customFormId (optional) — String key; must match an entry in components/cluster-config/studio-engine-forms.tsx if the generic GenericEngineClusterConfig is not enough.
• engineAffinity (optional) — false to omit from affinity, or { label?: string } for a custom dropdown label (default label is displayName).
• extraTypeAliases (optional) — Map of normalized API/type strings → canonical EngineDef.name for findEngineByType (e.g. alternate spellings).

Manifest: ui/queryflux-studio/lib/studio-engines/manifest.ts

• Import the new module and append it to STUDIO_ENGINE_MODULES (order affects ENGINE_AFFINITY_OPTIONS and registry iteration; catalog card order is separate — see below).

Derived registry: ui/queryflux-studio/lib/engine-registry.ts

• ENGINE_REGISTRY is STUDIO_ENGINE_MODULES.map((m) => m.descriptor). Do not duplicate descriptor arrays here.
• findEngineDescriptor, implementedEngines, isClusterOnboardingSelectable, validateClusterConfig — unchanged behavior; validateClusterConfig still uses generic required-field checks from configFields unless you extend the Rust/TS contract.

2. Catalog layout (picker order and dialect-only rows)

File: ui/queryflux-studio/components/engine-catalog.ts

• Implemented backends appear as studio slots: { k: "studio", engineKey: "<same key as descriptor>" } inside ENGINE_CATALOG_SLOTS, interleaved with static EngineDef rows (dialects with engineKey: null).
• At runtime, expandCatalog replaces each studio slot with studioModuleToEngineDef from lib/studio-engines/catalog.ts.
• Static STATIC_ENGINE_TYPE_ALIASES remains for dialects without a studio module; buildStudioTypeAliases() merges in per-module aliases and the lowercase engineKey → displayName mapping.

isClusterOnboardingSelectable still requires a catalog row with supported and engineKey; for studio-backed engines, supported is descriptor.implemented after expansion.

3. Cluster config forms

Router: ui/queryflux-studio/components/cluster-config/engine-cluster-config.tsx

• Resolves getStudioEngineModule(engineKey); if customFormId is set and STUDIO_CUSTOM_CLUSTER_FORMS[id] exists, renders that component; otherwise GenericEngineClusterConfig (descriptor configFields).

Custom form registration: ui/queryflux-studio/components/cluster-config/studio-engine-forms.tsx — map customFormId → component (see Trino / StarRocks / Athena).

Reference components: trino-cluster-config.tsx, starrocks-cluster-config.tsx, athena-cluster-config.tsx, generic-engine-cluster-config.tsx, config-field-row.tsx.

4. Persisted JSON ↔ flat form (create + edit save path)

File: ui/queryflux-studio/lib/cluster-persist-form.ts

• Still shared across engines. If cluster_configs.config gains new top-level JSON keys, update:
  • MANAGED_CONFIG_JSON_KEYS
  • persistedClusterConfigToFlat, flatToPersistedConfig, mergeClusterConfigFromFlat
  • buildValidateShape (shape expected by validateClusterConfig)
• validateEngineSpecific is implemented in lib/studio-engines/validate-flat.ts (per-module validateFlat); this file re-exports it for call sites.

5. Clusters page (grid, dialog, validation)

File: ui/queryflux-studio/app/clusters/clusters-grid.tsx

• Uses findEngineDescriptor, validateClusterConfig, validateEngineSpecific, buildValidateShape, skipImplementedCheck where needed. No per-engine branches beyond EngineClusterConfig.

File: ui/queryflux-studio/components/add-cluster-dialog.tsx

• Wires catalog → descriptor → EngineClusterConfig → toUpsertBody → upsertClusterConfig.

6. Group strategy (engine affinity)

File: ui/queryflux-studio/lib/cluster-group-strategy.ts

• ENGINE_AFFINITY_OPTIONS = buildEngineAffinityOptionsFromManifest(). To exclude an engine, set engineAffinity: false on its StudioEngineModule. To customize the label, use engineAffinity: { label: "…" }.

7. Display helpers

File: ui/queryflux-studio/lib/merge-clusters-display.ts

• Uses findEngineDescriptor(p.engineKey); the descriptor must exist in the manifest.

File: ui/queryflux-studio/components/ui-helpers.tsx (EngineBadge)

• Uses ENGINE_CATALOG; studio-expanded rows must match displayName where badges key off names.

File: ui/queryflux-studio/components/engine-icon.tsx

• Consumes EngineDef (re-exported from engine-catalog.ts; types in lib/engine-catalog-types.ts).

8. API types (usually unchanged)

File: ui/queryflux-studio/lib/api-types.ts

• ClusterConfigRecord / UpsertClusterConfig stay generic unless you add typed helpers.

9. Optional: fetch registry from the proxy

A follow-up could load GET /admin/engine-registry at runtime and hydrate forms from the API. Until then, keep Rust descriptor() and StudioEngineModule.descriptor in sync manually.

Studio checklist (copy-paste)

• lib/studio-engines/engines/<engine>.ts — StudioEngineModule (descriptor aligned with Rust, catalog, optional validateFlat, customFormId, engineAffinity, extraTypeAliases)
• lib/studio-engines/manifest.ts — import + append to STUDIO_ENGINE_MODULES
• lib/engine-registry-types.ts — extend ConnectionType / AuthType if needed
• components/engine-catalog.ts — add { k: "studio", engineKey: "…" } to ENGINE_CATALOG_SLOTS at the desired position
• components/cluster-config/studio-engine-forms.tsx — register component if customFormId is set
• lib/cluster-persist-form.ts — only if new persisted config JSON keys (managed keys + flat ↔ JSON + buildValidateShape)
• Smoke-test: Add cluster → save → edit → save; Engines page icons; group engine affinity if applicable

---

Part C — Frontend protocol (e.g. “more Postgres wire”)

Goal: clients speak a wire protocol to QueryFlux, not a new backend.

Where the code lives

• PostgreSQL wire: crates/queryflux-frontend/src/postgres_wire/
• MySQL wire: crates/queryflux-frontend/src/mysql_wire/
• Trino HTTP: crates/queryflux-frontend/src/trino_http/
• Flight SQL: crates/queryflux-frontend/src/flight_sql/

Typical steps

1. FrontendProtocol — Already defined in queryflux_core::query::FrontendProtocol; add a variant only for a new ingress protocol.
2. default_dialect() — Set the sqlglot source dialect for translation (see query-translation.md).
3. Listener — Bind a port, parse the protocol, build SessionContext and InboundQuery, then call shared dispatch_query (or the same helpers Trino HTTP uses).
4. Routing — Optionally extend protocol-based routing in config / persisted routing so this frontend maps to the right default group.
5. Tests — Protocol-level tests or e2e clients as appropriate.

Studio does not implement wire protocols; it only talks to the Admin API for config and metrics.

---

Checklist summary

Backend engine

• EngineConfig + EngineType + engine_key() + parse_engine_key() + From<&EngineConfig> for EngineType + dialect mapping (engine_registry.rs + query.rs)
• EngineAdapterTrait + descriptor()
• registered_engines.rs: all_descriptors() + build_adapter() arm calling try_from_cluster_config on the adapter
• Adapter module: try_from_cluster_config (or async equivalent) reading ClusterConfig
• UpsertClusterConfig::from_core / to_core stay aligned via engine_key / parse_engine_key (no extra string match in persistence)
• Translation / compatibility if dialect is new

Studio (UI)

• lib/studio-engines/engines/<engine>.ts — StudioEngineModule (descriptor + catalog + options)
• lib/studio-engines/manifest.ts — register module in STUDIO_ENGINE_MODULES
• lib/engine-registry-types.ts — ConnectionType / AuthType if Rust added variants
• components/engine-catalog.ts — { k: "studio", engineKey } slot in ENGINE_CATALOG_SLOTS
• components/cluster-config/studio-engine-forms.tsx — only if using customFormId
• lib/cluster-persist-form.ts — only if new config JSON keys need round-tripping
• Verify add-cluster + edit-cluster, Engines page icons / findEngineByType, and engine affinity if used

New client protocol

• FrontendProtocol + dialect + listener module + dispatch integration + routing docs

---

Related reading

• system-map.md — End-to-end flow
• query-translation.md — Dialects and sqlglot
• routing-and-clusters.md — Routers and groups
• observability.md — Admin API (including engine registry JSON)

Rust files referenced above

• crates/queryflux/src/registered_engines.rs — all_descriptors, build_adapter
• crates/queryflux-core/src/engine_registry.rs — engine_key, parse_engine_key, EngineRegistry, From<&EngineConfig> for EngineType
• crates/queryflux-persistence/src/cluster_config.rs — to_core / from_core vs engine_key + JSONB
